Tecline Military Line Metal Pressure Gauge (ø 52 mm) – 300 Bar

The Tecline Military Line 52mm Pressure Gauge is a highly reliable instrument designed to operate in the most extreme and rigorous diving conditions. Featuring an all-black look (black head and dial), this model is specifically developed for "Military" and avant-garde technical configurations that require an anti-glare profile, maximum hydrodynamic efficiency, and above-average structural resistance.

Technical and Construction Features

• Bronze Case with PVD Coating: The instrument body is entirely made of heavy bronze, coated with a special high-resistance PVD (Physical Vapor Deposition) treatment. This black finish not only eliminates reflections in the water but also offers unbeatable protection against abrasions, violent impacts, and salt corrosion.
• Maximum Mechanical Safety: Designed with a special safety grip on the pressure gauge head. This engineering solution prevents and precludes the projection or explosion of the glass in the improbable event of internal overpressure failure.
• High-Resistance Tempered Glass: The protective screen is made of crystalline tempered glass, immune to opacification and highly resistant to scratches caused by continuous contact with rocks, environments, or wrecks.
• High-Contrast Tactical Dial: Black background with a graduated scale and high-visibility numbering. The operating pressure is calibrated at 300 bar, with a full scale extended to 360 bar to ensure maximum reading accuracy even in the event of slight overpressure in the tank.

Technical Specifications

• Case Diameter: 52 mm (standard DIR size)
• Full Scale: 360 Bar (Operating Pressure: 300 Bar)
• Body Material: Bronze with Black PVD protective coating
• Lens: Tempered glass with integrated safety grip
• Line: Military Line - Tecline
• Compatibility: Suitable for any equipment configuration (Air, Nitrox, Oxygen) and ready for use with standard HP hoses (purchased separately).
